CMC Magnetics DVD+RW

Lite-ON LDW-401S, F/W ES0G, size written: 4.38GB

                            Media Information
Region information                                    N/A not a DVD-VIDEO
Media code/Manufacturer ID                                    CMC MAG W01
Format Capacity                                            4.38GB(4.70GB)
Free Blocks                                                             0
Book Type                                                          DVD+RW
Media Type                                                         DVD+RW
Media Id Code Speed                                         2.4x 3324KBps
Available Write Descriptor                           CLV  2.4x   3324KBps
BG Format Status                                                Suspended
Data area starting sector                                          30000h
Data area end sector                                              23053Fh
Linear Density                                                0.267um/bit
Track Density                                                0.74um/track
Number of Layers                                                        1

Complete Media Code:

00000000 08 02 00 00 92 0F 04 00 00 03 00 00 00 26 05 3F .............&.?
00000010 00 00 00 00 00 00 00 43 4D 43 20 4D 41 47 00 57 .......CMC MAG.W
00000020 30 31 00 39 23 00 8A 7A 62 02 1E 00 86 80 62 02 01.9#..zb.....b.
00000030 28 00 8A 7A 5E 02 1E 13 12 10 00 10 00 00 00 00 (..z^...........

Philips branded CMC Magnetics 2.4x DVD+RW written at 2.4x Nero CD/DVDSpeed

Memorex Dual-X, F/W 1.05, 4.38Gb data.

Region information                                    N/A not a DVD-VIDEO
Media code/Manufacturer ID                                    CMC MAG W01
Format Capacity                                            4.38GB(4.70GB)
Free Blocks                                                             0
Book Type                                                          DVD+RW
Media Type                                                         DVD+RW
Media Id Code Speed                                         2.4x 3324KBps
Available Write Descriptor                           CLV  2.4x   3324KBps
BG Format Status                                                Completed
Data area starting sector                                          30000h
Data area end sector                                              23053Fh
Linear Density                                                0.267um/bit
Track Density                                                0.74um/track
Number of Layers                                                        1

Full media code:

00000000 08 02 00 00 92 0F 04 00 00 03 00 00 00 26 05 3F .............&.?
00000010 00 00 00 00 00 00 00 43 4D 43 20 4D 41 47 00 57 .......CMC MAG.W
00000020 30 31 00 39 23 00 8A 7A 62 02 1E 00 86 80 62 02 01.9#..zb.....b.
00000030 28 00 8A 7A 5E 02 1E 13 12 10 00 10 00 00 00 00 (..z^...........

Sold as Verbatim datalifeplus DVD+RW 2.4X, manufactured by CMC Magnetics.

Sony DWU14A -> DRU510A burner.
Disc Regions are 1,2,3,4,5,6,7,8
Media code/Manufacturer ID CMC MAG W01
Format Type UDF 1.02
Volume Name AC_DC_DONINGTON
Application id
Implementation id AHEAD Nero
Recording Date/Time (mm/dd/yyyy) 12/25/2003 10:42:15
Format Capacity 4.38GB(4.70GB)
Book Type DVD+RW
Media Type DVD+RW
Media Id Code Speed 2.4x 3324KBps
Available Write Descriptor CLV 2.4x 3324KBps
BG Format Status Suspended
Data area starting sector 30000h
Data area end sector 23053Fh
Linear Density 0.267um/bit
Track Density 0.74um/track
Number of Layers 1

00000000 08 02 00 00 92 0F 04 00 00 03 00 00 00 25 EF 0F …%…
00000010 00 00 00 00 00 00 00 43 4D 43 20 4D 41 47 00 57 …CMC MAG.W
00000020 30 31 00 39 23 00 8A 7A 62 02 1E 00 86 80 62 02 01.9#…zb…b.
00000030 28 00 8A 7A 5E 02 1E 13 12 10 00 10 00 00 00 00 (…z^…

Media = HP DVD+RW 2.4X Rated (CMC Magnetics manuf.)


LiteOn LDW-451S GSB6

                            Media Information
Region information                                    N/A not a DVD-VIDEO
Media code/Manufacturer ID                                    CMC MAG W01
Format Capacity                                            4.38GB(4.70GB)
Book Type                                                          DVD+RW
Media Type                                                         DVD+RW
Media Id Code Speed                                         2.4x 3324KBps
Available Write Descriptor                           CLV  2.4x   3324KBps
BG Format Status                                                Suspended
Data area starting sector                                          30000h
Data area end sector                                              23053Fh
Linear Density                                                0.267um/bit
Track Density                                                0.74um/track
Number of Layers                                                        1


00000000 08 02 00 00 92 0F 04 00 00 03 00 00 00 22 51 DF ............."Q.
00000010 00 00 00 00 00 00 00 43 4D 43 20 4D 41 47 00 57 .......CMC MAG.W
00000020 30 31 00 39 23 00 8A 7A 62 02 1E 00 86 80 62 02 01.9#..zb.....b.
00000030 28 00 8A 7A 5E 02 1E 13 12 10 00 10 00 00 00 00 (..z^...........

Media=Memorex DVD+RW 2.4X


Liteon LDW-411S FS0H
Media Information
Region information N/A not a DVD-VIDEO
Media code/Manufacturer ID CMC MAG W01
Format Type UDF 1.02
Volume Name BETTER_LUCK_TOMORROW
Application id
Implementation id MEI
Recording Date/Time (mm/dd/yyyy) 7/15/2003 17:26:48
Format Capacity 4.38GB(4.70GB)
Book Type DVD+RW
Media Type DVD+RW
Media Id Code Speed 2.4x 3324KBps
Available Write Descriptor CLV 2.4x 3324KBps
BG Format Status Completed
Data area starting sector 30000h
Data area end sector 23053Fh
Linear Density 0.267um/bit
Track Density 0.74um/track
Number of Layers 1

			Media Code

00000000 08 02 00 00 92 0F 04 00 00 03 00 00 00 26 05 3F …&.?
00000010 00 00 00 00 00 00 00 43 4D 43 20 4D 41 47 00 57 …CMC MAG.W
00000020 30 31 00 39 23 00 8A 7A 62 02 1E 00 86 80 62 02 01.9#…zb…b.
00000030 28 00 8A 7A 5E 02 1E 13 12 10 00 10 00 00 00 00 (…z^…

Hewlett Packard 2.4X DVD+RW branded media

Burnt with Liteon LDW-401S -> 411S with firmware FS0H

Might have done this test before, but due to the bug in FS0G
performed a re-test to check out write ability and readability.

4X Read speed and 4ECC


Philips DVD+RW-D01 (soon to be changed to 811s)


Media Information
Disc Regions are                                          1,2,3,4,5,6,7,8
Media code/Manufacturer ID                                    CMC MAG W01
Format Type                                                      UDF 1.02
Volume Name                                                         Shrek
Application id
Implementation id                                              AHEAD Nero
Recording Date/Time (mm/dd/yyyy)                       9/17/2003 16:58:19
Format Capacity                                            4.38GB(4.70GB)
Book Type                                                          DVD+RW
Media Type                                                         DVD+RW
Media Id Code Speed                                         2.4x 3324KBps
BG Format Status                                            Not Formatted
Data area starting sector                                          30000h
Data area end sector                                              23053Fh
Linear Density                                                0.267um/bit
Track Density                                                0.74um/track
Number of Layers                                                        1


00000000 08 02 00 00 92 0F 04 00 00 03 00 00 00 26 05 3F .............&.?
00000010 00 00 00 00 00 00 00 43 4D 43 20 4D 41 47 00 57 .......CMC MAG.W
00000020 30 31 00 39 23 00 8A 7A 62 02 1E 00 86 80 62 02 01.9#..zb.....b.
00000030 28 00 8A 7A 5E 02 1E 13 12 10 00 10 00 00 00 00 (..z^...........


Lite-ON LDW-811S, F/W HS0K, size written: 4.38GB booktype set to DVD-ROM
ID: CMC MAG W01
Disc Type = DVD-ROM
Manufacturer = CMC Magnetics Corporation

<< Disc Information >>
Erasable = True
Status of Last Session/Border = Complete Session/Border
Disc Status = Complete Disc
Number of First Track/RZone on Disc = 1
Number of Sessions/Borders(LSB) = 1
First Track/RZone Number in Last Session/Border(LSB) = 1
Last Track/RZone Number in Last Session/Border(LSB) = 1
Disc Identification Valid(DID_V) = False
Disc Bar Code Valid(DBC_V) = False
Unrestricted Use Disc(DRU) = True
Disc Type = CD-DA or CD-ROM Disc
Disc Identification = 00000000h
Lead-in Start Time of Last Session = 00:00:00(00:00:00h)
Last Possible Start Time for Startof Lead-out = 00:00:00(00:00:00h)
Disc Bar Code = 0000000000000000h
Number of OPC Table Entries = 0
<< Track Information >>
Number of Complete Sessions on Disc = 1

Imation DVD+RW 4.7 GB no speed mentioned.
Burned at 2.4x, scanned at 4x, ECC=8


Benq DW1655 BCIB, 1282 MB burned at 4×

sold as “HP DVD+RW 4× 1,4 GB”
MID: CMC MAG W02 (CMC Magnetics)


Canon DC22 Digital Camcorder burned at 1x (?)

Sold as Memorex DVD+RW 4x
MID: CMC MAG W02 (CMC Magnetics)

Lite-On iHBS112 CL04, 1396 MB burned at 4×

sold as “TDK mini Colour DVD+RW 4× 1,4 GB”
MID: CMC MAG-W02-000

hub code: PWD668 LE01103886 0A03 0
stamper code: DVD+RW 8CMOD-018 0109

#01




TSST SH-S223F SB03, 1396 MB burned at 4×

sold as “TDK mini Colour DVD+RW 4× 1,4 GB”
MID: CMC MAG-W02-000

#02



Lite-On iHBS212 HL05, 1394 MB burned at 4x

sold as “HP 4x 1,4 GB DVD+RW”
MID: CMC MAG W02
made in Taiwan
